ACL 2位3通直動式閥Direct Acting 312

ACL 2位3通直動式閥Direct Acting 312

說明

電磁閥3通直接作用提升閥類型

法蘭固定

構造

車身黃銅

電樞管黃銅

柱塞和芯AISI 430FR .

彈簧AISI 302

密封材料NBR-FPM-EPDM

功能

最大允許壓力PS 50bar口

最大流體粘度25cSt ( mm2/s )

環境溫度:根據線圈,從-10°C到+80°C

通用安裝位置

DESCRIPTION

Solenoid valve 3 way direct acting poppet type

Flange fixing

CONSTRUCTION

Body Brass

Armature tube Brass

Plunger and core AISI 430FR

Springs AISI 302

Seal material NBR - FPM- EPDM

FEATURES

Maximum allowable pressure PS 50bar]

Maximum fluid viscosity 25cSt (mm2/s)

Ambient temperature: from -10°C to +80°C according to the coil

Universal mounting position

3/2 Direct Acting NO

TYPE

PORT SIZE

ORIFICE

Kv

DIFFERENTIAL PRESSURE ΔP bar

NOMINAL POWER

COIL

SEAL

TEMPERATURE RANGE

mm

m3/h

MIN

MAX

AC-VA

DC

width

TYPE

1-2

2-3

AC

DC

INRUSH

HOLDING

W

°C

312 NO

25 Flangia base

1.5

1.5

0.06

0

10

10

12

8

6.5

22

3

NBR EPDM FPM

-10 +90 -10 +140 -10 +140
