WIKA 232.50.100波登管壓力表，不銹鋼型 - 副本

WIKA 232.50.100
波登管壓力表，不銹鋼型
過程壓力儀表，安全型，符合ASME B40.100標準，NS 4 1/2"

應用

具有更高安全要求的應用
帶可充液外殼，可用于具有高動態壓力脈沖或振動的應用場合
適用于腐蝕性環境以及不粘滯的氣體或液體介質
過程工業：化工、石化、發電站、采礦、沿海和離岸平臺、環保技術、機械制造和設備建造
功能特性

帶實心隔板設計（符合ASME B 40.1操作安全性要求）的安全壓力表
卓越的負載循環穩定性和抗沖擊性能
測量范圍：高達0 ... 100 MPa
WIKA 232.50.100
Bourdon tube pressure gauge, stainless steel
Process Gauge, safety version per ASME B40.100, NS 4 1/2"

Applications

Increased safety requirements
With liquid filled case for applications with high dynamic pressure pulsations or vibrations
Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
Process industries: chemical/petro-chemical, power stations, mining, on- and offshore, environmental technology, mechanical engineering and plant construction
Special Features

Safety pressure gauge with solid baffle wall designed in compliance with operational safety requirements of ASME B 40.1
Excellent load-cycle stability and shock resistance
Scale ranges up to 0 ... 1000 bar
